Flat cable cutting and stripping machine WPM-E-12
Features:
This model is designed for stripping and cutting flat cables (flat wires), the Max. available cable width is up to 30mm, you can set the stripping length, cutting length, and other parameters through the LCD, then it will strip and cut your wires full automatically!
Specifications:
Available Core Cross-Section Range: 0.1 - 4.0mm2
Max. Width for Flat Cable: 30mm
Cutting Length: 5 ~ 9999mm
Stripping Length: Head 0~35mm, End 0~15mm
Memory Function: Can store Max. 99 group programs
Max. Middle Stripping Section: 11
Cutting Tolerance: ±(0.002×L) (L=Cutting Length)
Speed: 3000~8000pcs/hour
Display Way: English LCD display
Drive Mode: Four-wheel drives
Blade Material: Hard tungsten steel
Appropriate Wire: flat cable, data cable, flat wire
Power Supply: 220V/50Hz 110V/60Hz
Power Rating: 300W
