Automatic Terminal Crimping Machine Blades Set - DC53 Steel JW-BL03

📅 2023-01-06 👁️ 1,019
  • Model No: JW-BL03

  • Specifications

    Material: DC53 Steel
    Quality Control: US Niton Spectrometer Tested
    Components: Upper Outer Cut, Upper Inside Cut, Lower Outer Cut, Lower Inside Cut, Upper Cutter, Lower Cutter, Cushion1, Cushion2
    Functions: Cable End Cutting, Wire Stripping, Wire Cutting
  • Inquiry now

JW-BL03 is a complete blade set for automatic terminal crimping machines. The set covers eight positions - upper outer cut, upper inside cut, lower outer cut, lower inside cut, upper cutter, lower cutter and two cushions - so one order restores the whole cutting and stripping station instead of replacing blades one at a time.

All cutting parts are DC53 steel and each batch is checked on a US Niton spectrometer before dispatch, so the alloy is verified rather than assumed. The upper blades carry a narrow neck below a wide body, which lets the tip enter between insulation and conductor; the lower blades are block form with the wire trough cut across the top face. Together they perform three functions on one station: cable end cutting, wire stripping and wire cutting.

It is used on automatic terminal crimping machines that run the OTP blade pattern, and the set is normally replaced as a group because the upper and lower halves wear against each other. The lower blocks are held by two screws and the cushions take up the closing clearance, so a full set keeps strip depth stable after the change.

Key Features

1. Material: DC53 steel across all eight cutting parts, so upper and lower blades wear at a comparable rate.

2. Verification: each batch is tested on a US Niton spectrometer, confirming the alloy before packing.

3. Upper blade form: 15 mm and 20 mm wide body on a 48 mm length, narrowing to a 6 mm neck at the cutting tip.

4. Upper blade fixing: 8 x 10 mm mounting hole, matching the standard terminal machine blade pin.

5. Lower blocks: outer block 20 x 14 mm with 6.5 mm holes; inner block 30 x 30 mm, both two-screw fixed.

6. Complete set: eight parts covering end cutting, stripping and wire cutting, replaced as one group.

Technical Specifications

ParameterSpecification
ModelJW-BL03
Set contentUpper/lower outer cut, upper/lower inside cut, upper/lower cutter, 2 cushions
MaterialDC53 steel
Quality controlUS Niton spectrometer tested
Upper blade width15 mm and 20 mm (photo)
Upper blade length48 mm (photo)
Neck width6 mm (photo)
Mounting hole8 x 10 mm (photo)
Lower outer block20 x 14 mm, 6.5 mm holes (photo)
Lower inner block30 x 30 mm (photo)
FunctionsCable end cutting, wire stripping, wire cutting

Applications

— Automatic terminal crimping machines with the OTP blade pattern - end cutting, stripping and wire cutting in one station.

— Wire harness lines running discrete leads, where the strip depth has to stay constant over a long run.

— Rebuilt terminal machines where the original blade group is worn as a set and clearances have opened up.

— Multi-terminal production, with one complete set held per machine for changeover and spare.

— Machines cutting and stripping flat material belt as well as single conductors.

OTP die cutter set with upper, inside and under cutters plus cushionsTwo OTP die cutter blades for terminal machine mold, top viewUpper cutter, under cutter and cushion blocks in brushed steelCutter parts, crimped terminal strip sample and four selling pointsDC53 steel blade, spectrometer test and vacuum quenching processSix crimping die parts including upper cutter, punches and cushionsFour terminal crimping blade sets labeled JC2.0, PH and SMPH blade dimension drawing with 48 mm and 57 mm heightsIn-ear, mobile phone and over-ear speaker parts as application examples
