Automatic Water Activated Gummed Tape Dispenser Machine AT JW-TP03
Model No: JW-TP03
Specifications
Automatic Water Activated Gummed Tape Dispenser Machine ATVoltage: 210-230VTape Width: 4-8cmPower: 200WSpeed: 30cm/sWeight: 12kg- Inquiry now

The JW-TP03 dispenses water-activated gummed paper tape from 4 cm to 8 cm wide at 30 cm/s, wetting the adhesive side as the tape leaves the roll and cutting it to a preset length. It runs on 210-230 V with a 200 W motor and weighs 12 kg.
Gummed paper tape only bonds when the starch adhesive is wetted evenly: too little water and the tape lifts at the carton edge, too much and the paper cockles. The JW-TP03 draws the tape over a wetted roller fed from the reservoir in the top cover, then feeds and cuts it in one pass. Preset length keys from 15 cm to 100 cm on the front keypad repeat the lengths used for box flaps, so the sealing station does not measure tape by hand.
The RT-3000 and ZCUT-80 cut pressure-sensitive tape, which bonds on contact and needs no water, and the M-1000 handles 7-50 mm plastic tape over a 20-999 mm length range. The JW-TP03 works only with gummed paper tape: 4-8 cm width, 30 cm/s feed and a 12 kg body that stays in place while the cut strip is pulled onto the carton.
1. A 4-8 cm tape width covers standard 48 mm and 72 mm gummed paper tape on one machine.
2. A 30 cm/s feed speed from a 200 W motor on a 210-230 V supply.
3. A water tank feeds the wetting roller, so the starch adhesive is activated immediately before the strip leaves the machine.
4. Preset length keys from 15 cm to 100 cm, plus start and stop keys, repeat common flap lengths without a measuring step.
5. A 12 kg body keeps the dispenser steady when the cut strip is pulled away onto the carton.
6. Cuts gummed paper tape to length in one pass and delivers the strip at the front slot ready to place on the carton.
| Parameter | Specification |
|---|---|
| Model | JW-TP03 |
| Machine type | Automatic water-activated gummed tape dispenser |
| Voltage | 210-230 V |
| Tape width | 4-8 cm |
| Power | 200 W |
| Speed | 30 cm/s |
| Weight | 12 kg |
| Preset lengths | 15-100 cm on the front keypad |
— Export carton sealing: gummed paper tape on corrugated boxes for single-material, recyclable packaging.
— E-commerce fulfilment: repeatable 40-60 cm tape lengths for box flap sealing at a packing bench.
— Agricultural cartons: paper tape sealing where a water-based adhesive is preferred to a solvent acrylic.
— Archive and document boxes: tamper-evident paper tape closure that shows if the carton has been reopened.
— Coil and cable drum cartons: heavy paper tape for cartons that are stacked after sealing.
