Handheld Automatic Screw Locking Assembly Machine WPM-801

📅 2026-03-19 👁️ 2,579
  • Model No: WPM-801

  • Specifications

    Model Number: WPM-801
    Efficiency: 50-70pcs/MIN (Depends on screw length)
    Voltage: 220V/50Hz
    Screw-feeding Speed: 0.75sec/p
    Power: 30W
    Weight: 9kg
    Dimension: 370*250*190mm
    Noise: lower than 65db
    Distance: 1-4M
  • Inquiry now

The WPM-801 is a hand-held automatic screw locking machine. The driver is a pistol-grip unit connected by a 1-4 m tube to a 9 kg feeder cabinet; screws are blown through the tube to the bit, so the operator positions the tool and pulls the trigger without picking up a screw. Output is 50-70 pcs/min, depending on screw length.

Manual assembly loses time at the pick-up rather than at the drive: reaching into a tray, orienting the screw and starting it straight accounts for most of the cycle. In the WPM-801 the screw arrives at the bit in 0.75 s per piece, already aligned with the driver axis, and the feeder counts each screw on a digital display so a short feed is visible before a screw is missed. The cabinet groups the air regulator, filter, pressure gauge and emergency stop, and feed noise stays below 65 dB.

The WPM-801 is the hand-positioned member of the screwdriving range. The WPM-802 three-axis table drives at 3-5 seconds per workpiece and suits flat parts that can be fixtured, and the WPM-803 four-station rotary machine is built for volume on small housings. The WPM-801 is the choice when the workpiece is too large, too heavy or too awkward to bring to a table, or when several operators work on one assembly.

Key Features

1. 50-70 pcs/min output, governed by screw length and thread engagement.

2. Screw feed time of 0.75 s per piece from the feeder to the bit.

3. 1-4 m feed hose, so the 9 kg cabinet can stand on the floor or a bench away from the work position.

4. 30 W at 220V/50Hz; cabinet measures 370 x 250 x 190 mm and the complete set weighs 9 kg.

5. Feed noise below 65 dB, low enough to run in an open assembly cell.

6. Front panel groups the emergency stop, digital screw counter, air regulator, filter and pressure gauge, so feed pressure is trimmed at the machine.

Technical Specifications

ParameterSpecification
Model NumberWPM-801
Efficiency50-70 PCS/MIN (depends on screw length)
Voltage220V / 50Hz
Screw-feeding speed0.75 sec/piece
Power30 W
Weight9 kg
Dimension370 x 250 x 190 mm
Noiselower than 65 dB
Feed distance1-4 m

Applications

— Consumer electronics: assembling small appliance housings and control boxes with M2-M4 screws.

— Cable harness and connector assembly: fixing strain-relief clamps and connector shells.

— Furniture and shelving hardware: driving screws into flat-pack panels at fixed stations.

— Electrical panels: fastening terminal blocks, DIN rail components and covers.

— Automotive aftermarket: assembling lamp housings and brackets that cannot be moved to a table.
