Automatic Wire Cutting & Stripping Machine with Double Tie WPM-CPRT-02TH

Name: Automatic Wire Cutting & Stripping Machine with Double Ti...
Brand: JINGWEI
SKU: WPM-CPRT-02TH
Availability: InStock
Rating: 5 (1 reviews)

Large circle double tie type automatic meter cutting wire stripping and winding machine, as well as automatic tying machines, wire/cable bundle tying machines, and wire tying machines are available.
Applicable wire diameter 2-5mm
Cutting length 3-40m
Cutting line length accuracy: ±2mm/m
Round tie appearance single/double tie strap, split end, and end, diagonal side
The inner diameter of the circle is 300-400mm (adjustable)
Binding diameter ≤40mm
Desquamation mode complete desquamation at both ends
Head and tail peeling length 20-50mm (adjustable)
Head retention length 250-300mm (adjustable)
Tail length 300-400mm (random value within the interval)
Production efficiency: 180-300pcs /H (2-40m)
Applicable binding tape: Coated iron core ≤ 7.5kg/roll
Power supply: NATIONAL standard 220V/50Hz
Machine power: 4.5KW/H
Machine size: about 2500L*1100W*1850Hmm
Machine weight: about 1000KG

Main accessories:
Cylinder: Yadeke cylinder and solenoid valve
Motor: Winding main servo motor 1500W Turbot
Motor: take line translation servo motor Turbot 750W
Motor: online translation servo motor Dongling 750W
Motor: winding up and down 57-step thunder race
Motor: Twisting and strapping belt spitting belt 57 stepper motor thunder race
Motor: storage tape motor 6W
Slide block: take line translation double slide block
Guide rail: lower paw translation double guide rail
PLC: vigor
Screen: Dimension control 7"
Power supply: clear weft
Frame: the iron frame is painted blue and white
Safety protection: stop when the door opens
Lack of material alarm: three-color lamp buzzes
Frame: the appearance of iron frame is painted blue and white
Supporting high-speed active winding machine CY-P01-150KG features:
Automatic frequency conversion, step-less variable speed,
With line storage function
Tension function
Deceleration function
Incoming material capacity ≤100KG
Incoming wire tray inner hole diameter 60-80mm
The outer diameter of the incoming hollow reel is ≤630mm
The thickness of the incoming wire coil is ≤500mm
Machine power: 2.2KW
Machine size: about 1450L*800D*980Hmm
Machine weight: about 150KG

What are the key capabilities of the WPM-CPRT-02TH Automatic Wire Cutting & Stripping Machine?

The WPM-CPRT-02TH is a fully automated industrial wire processor designed for precision cable harness manufacturing. Its core capabilities include cutting wire lengths from 3 to 40 meters with high accuracy (±2mm per meter), automatically stripping insulation from both ends of the wire, and securing the finished bundle with two durable straps. It efficiently handles wire diameters between 2mm and 5mm, delivering a consistent output of 180 to 300 processed pieces per hour.

How does the 'double tie' feature benefit my wire processing operation?

The integrated double tie function ensures superior bundle security and organization. By applying two straps to each wire bundle, it prevents tangling, maintains wire alignment during handling and shipping, and is ideal for creating neat, professional cable harnesses. This feature enhances workflow efficiency downstream, reduces manual rework, and is perfect for applications requiring reliable, kink-free wire management in industries like automotive, appliance manufacturing, and control panel assembly.

What is the production speed and power requirement for this machine?

The WPM-CPRT-02TH operates at a production speed of 180 to 300 pieces per hour, depending on the wire length and complexity. It is powered by a robust 4.5KW motor and runs on a standard 220V electrical supply, making it suitable for most industrial workshop environments. This balance of speed and power ensures high-volume throughput while maintaining the precision required for meter cutting and stripping tasks.

What types of wire or cable can this machine process?

This automatic wire cutting and stripping machine is engineered to process a wide range of single-core wires commonly used in harness manufacturing. It is optimized for wires with an outer diameter between 2mm and 5mm. For optimal performance and to prevent damage to the stripping blades, we recommend inquiring with our technical team regarding the compatibility of specific cable types, such as those with specialized jacketing or shielding.

Is this machine suitable for creating finished cable harnesses ready for installation?

Yes, absolutely. The WPM-CPRT-02TH is a complete wire processing solution that transforms raw cable reels into finished, bundled harness components. By integrating cutting, stripping, and tying into one automated cycle, it outputs wire bundles that are cut to precise lengths, stripped for termination, and securely tied for handling. This makes it an ideal industrial wire processor for manufacturers seeking to automate their cable harness production line, improve consistency, and reduce labor costs.
