The Cut-100D to WPM-Cut-1200 is a bench-top automatic stacking cutting machine for rolled fabric, non-woven, tape and wire. Material is drawn off an unwind stand by powered rollers, cut to a programmed segment length, and delivered as a stack of flat pieces. The series runs from the narrow Cut-100D through to the WPM-Cut-1200; the standard configuration is quoted at a 120–515mm cutting width.
Cutting roll goods by hand gives a ragged edge, and gathering loose pieces afterwards takes a second operator. On this machine the unwind stand holds the roll under tension, the feed rollers advance the web by the programmed length, and the blade bar cuts across the full width in one pass; the piece drops onto the stacking tray already aligned. Segment length is entered on the controller from 0.1mm to 99999.9mm, at 0.1mm accuracy and a feed speed of 80m per minute.
This is the roll-fed stacking machine in the cutting group, working at 120–515mm width with a maximum cut length of 100m. The WPM-6100 beside it is a narrower digital cutter for ribbon and tape, up to 200mm wide, running 100–120 pieces per minute at ±0.1mm, and it counts pieces rather than stacking them. Choose the stacking machine for wide web and long segments, the 6100 for narrow tape in counted batches.
Key Features
1. Cutting width of 120–515mm in the standard configuration, with the series extending from Cut-100D to WPM-Cut-1200 for wider webs.
2. Segment length programmable from 0.1mm to 99999.9mm, with a maximum cut length of 100m per piece.
3. Feed speed of 80m per minute, set from the controller to match the material and the cut length.
4. Cutting accuracy of 0.1mm held by the roller feed, which advances the web by the programmed length before each blade stroke.
5. Unwind stand with adjustable arms carries the roll and holds the web under tension into the feed rollers.
6. Stacking tray behind the blade bar receives each cut piece flat, so the stack stays square without a second operator.
Technical Specifications
| Parameter | Specification |
|---|
| Model | Cut-100D to WPM-Cut-1200 |
|---|
| Machine type | Automatic Stacking Cutting Machine |
|---|
| Cutting Width | 120mm to 515mm |
|---|
| Max Cut Length | 100M |
|---|
| Speed | 80M/Minute |
|---|
| Accuracy | 0.1mm |
|---|
| Segment Length Range | 0.1–99999.9mm |
|---|
| Power Supply | 220V 50/60HZ |
|---|
Model Range at a Glance
Ten cutting machines from WPM-Cut-100D to WPM-Cut-1200. Cutting width grows in line with the model number, while cutting length, speed and accuracy are identical across the range.
| Parameter | WPM-Cut-100D | WPM-Cut-200 | WPM-Cut-300 | WPM-Cut-400 | WPM-Cut-500 | WPM-Cut-600 | WPM-Cut-700 | WPM-Cut-800 | WPM-Cut-1000 | WPM-Cut-1200 |
|---|
| Cutting width | 120 mm | 215 mm | 315 mm | 415 mm | 515 mm | 615 mm | 715 mm | 815 mm | 1015 mm | 1215 mm |
|---|
| Max cutting length | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
|---|
| Speed | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min | 80 m/min |
|---|
| Accuracy | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm | 0.1 mm |
|---|
Applications
— Non-woven converting, cutting rolls of wadding, felt and lining into panels for stitching.
— Textile and garment trimming, cutting binding tape and bias strips to fixed lengths before assembly.
— Cable and wire processing, cutting flexible cable, sleeving and braided tube into harness segments before termination.
— Packaging, cutting foam sheet, bubble wrap and barrier film into inserts of consistent length.
— Filter media production, cutting flat and pleated media to segment length for element assembly.
