Taping Machine for Wire Coils, Semi-automatic adhesive tape wrapping wire coil machine
Product Description
This is a semi-automatic tape wrapping-around machine for taping wire coils. The taping speed is within 1.5s.
1. Taping speed: within 1.5s
2.Applicable tape width: 12mm-18mm
3.Max tape OD: 120mm
4. Tape cutting range: 45mm-75mm
5. Replace the adhesive tape: the old and new adhesive tapes are bonded end to end.
6. The taping tightness is subject to the existing mold. If there is a special product, it is necessary to customize the reel according to the product size.
7. The vulnerable parts of this machine are paper cutting scissors, paper roll, and contact switch.
8. Other electrical components are guaranteed for one year, except for damage caused by man-made and irresistible factors.
Specification
Model Number |
WPM-75 |
Usage |
WINDING |
Application |
wire coil tapping |
Taping speed |
1.5S |
Tape inner diameter |
76mm |
Tape outer diameter |
diameter Max 120mm |
Voltage |
220v 50hz, 0.55kw |
Cutting length |
45-75 mm |
Tape width |
12-18mm |
Air pressure |
4kg/cm2 |
Size |
670x390x480 mm |
Weight |
30kg |
