The WPM-K287 winds an iPhone data cable onto a fixture in the coil shape used by retail paper cards, then closes a tie if the pack calls for one. The winding fixture and the fixed wire shaft sit on top of the cabinet, and the operator starts the cycle from a foot pedal, which leaves both hands for the lead and the card. Coil count, tie count and tie length are all customizable, so the same machine is set for one card style and re-set for the next. It takes USB, headphone, AC/DC power, network, telephone and audio/video cable, including HDMI.
Winding a cable for a printed card by hand is a packaging job rather than a production job: the coil has to sit inside the card cutout, the two connector ends have to land in the same place, and the operator judges both by eye. The K287 winds to a fixed fixture instead, so the coil size is set by the tooling and the ends land where the card expects them, and the foot pedal keeps the cycle to one press per cable. The paper card types listed for the machine are the Apple 11th generation, Apple generation 8, Apple generation 7 and F-type cards, with other cards customized and tested on request.
Compared with the WPM-K289, which is automatic, banded with silicone and rated 2-8 circles per second over 50-200 mm, the K287 is the manual-feed unit at 20 kg on a 400 x 360 x 300 mm frame, and it is built around the paper card rather than the banded bundle. Against the 212 series coilers, which form 50-250 mm coils and close a twist tie, this machine works at the smaller coil size a card takes and finishes the lead for a boxed retail pack. Where a line runs several card styles in small batches, the K287 is re-tooled rather than re-programmed.
Key Features
1. Winding fixture and fixed wire shaft set the coil to the paper card, so the coil and the connector ends land in the card position.
2. Paper card types listed: Apple 11th generation, Apple generation 8, Apple generation 7, F-type; other cards customized and tested on request.
3. Number of coils, number of ties and tie length are all customizable per card style.
4. Foot pedal starts the cycle, leaving both hands free to hold the lead and the card.
5. PLC program with LCD text parameter setting and a stepper motor with brake control for the winding stop.
6. Runs USB, headphone, AC/DC power, network, telephone, audio/video and HDMI cable; 20 kg on a 400 x 360 x 300 mm cabinet.
Technical Specifications
| Parameter | Specification |
|---|
| Model | WPM-K287 |
|---|
| Type | Semi-automatic winding and binding machine |
|---|
| Control system | PLC program with LCD text parameter setting |
|---|
| Motor | Stepper motor with brake control |
|---|
| Operation | Foot pedal activated |
|---|
| Suitable for | USB cable, headphone cable, AC/DC power cable, network cable, telephone cable, audio/video cable, HDMI cable |
|---|
| Paper card types | Apple 11th generation, Apple generation 8, Apple generation 7, F-type; others customized |
|---|
| Customization | Number of coils, number of ties, cable tie length |
|---|
| Dimensions | 400 x 360 x 300 mm |
|---|
| Weight | 20 kg |
|---|
Applications
— iPhone and USB data cable packing: wound onto the Apple-style card before it goes into the retail box.
— Consumer electronics OEM lines: cable and card assembled to the pack drawing, with the coil count set per card.
— Headphone and audio lead packing: leads wound to the card cutout for boxed retail.
— Network and telephone cable kitting: patch leads wound and tied for kit packing.
— Contract packers: several card styles run on one machine by changing the fixture and the coil count.
